FEATURES

All ADVS is fitted with non-cloggin high efficiency vortex impeller with solid pass of 30 – 55mm. It feature auto adjustable reliable double mechanical seal to prevent any leaking.  ADVS pumps has a dynamic impeller with high efficiency and anti-wearing.

APPLICATION

• Industrial Sewage Water Intake
• Environmental protection system

TECHNICAL DATA

• Liquid temperature 0°C to 40°C
• Ambient temperature max 40°C, pH 6 to 8
• Motor range : 1 Hp to 5 Hp / 0.75 kW to 3.7 kW
• Rated speed : 2900 rpm / 3450 rpm
• Capacity up to 1200 l/m
• Protection class : IP 68
• Max depth : 8 m
• Solid pass 40 ~ 75 mm
